    Default AWESOMEEEE mini surge

    STEPS TO BUILD IT!

    1) The U-tube - I made mine with a U- tube i had laying around and extended it a little longer on the end for more water. Also drill a hole above your water line, this is a air release.
    surgedevice001 - AWESOMEEEE mini surge
    2) The OUTLET - Decided how you want it to enter the tank with some type of director, i used a 2 way deflector and I'm goning plug on outlet to make it stronger but you could use anything you have.
    surgedevice002 - AWESOMEEEE mini surge
    3) CUT HOLE IN WATER CONTAINER - You can use any water container you want, i just had a gallon jug available so its what i used, you could use something allot nicer.
    surgedevice003 - AWESOMEEEE mini surge
    4) PUMP AND HOSE - You only need a small pump nothing to large unless you are doing a huge surge device for a big tank. Connect hose to pump.
    surgedevice004 - AWESOMEEEE mini surge


    ASSEMBLY

    - Hose in top of container
    - Shorter end of U-tube in container hole
    - Attach water deflector on outlet
    - Mount above tank
    - Plug in


    FINISHED PRODUCT


    INSTALLED ONTO TANK



    THE ULTIMATE MINI SURGE DEVICE!


    Print out the steps


    Corvette Reefers contest entry
    Last edited by Corvette Reefer; 05-07-2011 at 03:24 PM.
    The names Vette, Corvette. . .

  2. #2
    Sir Patrick - Reefkeeper A2 Club Coordinator
    Join Date
    Oct 2009
    Location
    UofM territory
    Posts
    7,475
    First Name
    Chris
    Awards Monthly Giveaway Winner

    Default

    Looks like you need a bigger out put hose, or a slower pump. The surge is lasting far too long. So far, I like the idea.

    Be carefull w/ the surge disturbing your sand bed- it will cause issues.

  3. #3
    Corvette Reefer - Reefkeeper CR Member
    Join Date
    Nov 2009
    Location
    Dexter, Michigan
    Posts
    421

    Default

    yeah im gona take off the extension on the you tube and to make faster surges, ill finish tomorrow, and do some more stuff to the thread to make it fancier.
    The names Vette, Corvette. . .

  4. #4
    MizTanks - Reefkeeper
    Join Date
    Oct 2009
    Location
    U.P. of Michigan.
    Posts
    7,553
    First Name
    Jamie
    Awards Photo of the Month - October 2012 Photo of the Month Post and Reply Award - Winner of the first PAR Contest. Monthly Giveaway Winner

    Default

    What is a surge? Purpose?
    There's nothing like being a Reefer! www.upmmas.com

  5. #5
    Sir Patrick - Reefkeeper A2 Club Coordinator
    Join Date
    Oct 2009
    Location
    UofM territory
    Posts
    7,475
    First Name
    Chris
    Awards Monthly Giveaway Winner

    Default

    A surge is a large amount ow water flow, let loose all at once, with a pause in between surges. Its one of the many types of water movement available in our reef tanks.

    Imagine the bucket in the videoo being his tank, and the bottle of water hanging over it.

  6. #6
    MizTanks - Reefkeeper
    Join Date
    Oct 2009
    Location
    U.P. of Michigan.
    Posts
    7,553
    First Name
    Jamie
    Awards Photo of the Month - October 2012 Photo of the Month Post and Reply Award - Winner of the first PAR Contest. Monthly Giveaway Winner

    Default

    I've never heard of this. What are the benefits?
    There's nothing like being a Reefer! www.upmmas.com

  7. #7
    Corvette Reefer - Reefkeeper CR Member
    Join Date
    Nov 2009
    Location
    Dexter, Michigan
    Posts
    421

    Default

    Its like a wave maker, corals like it better and it helps them grow too. Basically it makes the corals happier! :D
    The names Vette, Corvette. . .

  8. #8
    Sir Patrick - Reefkeeper A2 Club Coordinator
    Join Date
    Oct 2009
    Location
    UofM territory
    Posts
    7,475
    First Name
    Chris
    Awards Monthly Giveaway Winner

    Default

    Looks great man!

  9. #9
    CableGuy - Reefkeeper CR Member
    Join Date
    May 2010
    Location
    SCS,MI
    Posts
    361
    First Name
    Adam

    Default

    Very cool!

  10. #10
    Corvette Reefer - Reefkeeper CR Member
    Join Date
    Nov 2009
    Location
    Dexter, Michigan
    Posts
    421

    Default

    thanks guys
    The names Vette, Corvette. . .
